EP24F3B-2.0
$2,295.00
⚙ EPOCH HVLS FANS — TECHNICAL SPECIFICATIONS ⚙
EPOCH 2.0 SERIES
Epoch 24-ft | 3-Blades | 63 RPM HVLS Fan
Epoch 2.0 Motor & Controller — 90 Nm / 0.8 kW / 1.1 hp
Technical Specifications – 24 ft (7.3 m)
| Fan Diameter | 24 ft (7.3 m) |
|---|---|
| Number of Blades | 3 |
| Blade Profile | Airfoil Design (Falcon-inspired + aeronautics) |
| Blade Material | Anodized 6061-T6 Aluminum |
| Blade Struts | Clear Zinc / High Tensile Steel |
| Blade Width / Thickness | 187 mm / 2 mm |
| Blade End | Winglets (Nylon) |
| Coverage (max) | 17,000 sq.ft. (1,578 m²) |
| Coverage Radius | 40 ft |
| Space Between Fans (recommended) | 72 ft |
| Min. Space from Wall | 36 ft |
| Air Flow (CFM) | 300,000 – 330,000 CFM |
| Sound Level | < 35 dB |
| Approx. Fan Weight | 78 kg / 172 lbs |
Motor & Electrical – Epoch 2.0
| Motor Platform | Epoch 2.0 (Falco) – Direct Drive PMSM |
|---|---|
| Technology | UPF (Unity Power Factor) + PMSM |
| Max Speed (RPM) | 63 RPM |
| Power @ Max RPM | 800 W (1.1 hp) |
| Torque @ Max RPM | 90 Nm |
| Standard Power Input | 200–277V AC, 1~, 50/60 Hz |
| Operating Units Options | Wireless / Smartphone Apps · Touch LCD (Modbus) · Analog · Analog + LCD |
Safety & Certifications
| Safety System |
• Safety guy wire for motor + each blade • Automotive-grade hub and guy wires • Designed for UL507 (fans), UL1004 (motor), UL60730-2-9 / UL508C (drive) |
|---|---|
| Warranty | See Warranty Information (available on request) |
OVERVIEW
Airfoil Design & Product Overview
Epoch HVLS Fans with PMSM motor & direct drive meet international standards for quality, safety and performance. The airfoil and blade design combines modern aeronautics with the wing structure of a falcon to create a remarkably dynamic and efficient airflow at every speed. Blades dynamically adjust the angle using advanced aeronautics principles to optimise air movement across the massive 24-ft sweep.
