Epoch 1.0 – 6 ft HVLS Fan Specifications
⚙ EPOCH HVLS FANS — TECHNICAL SPECIFICATIONS ⚙
EPOCH 1.0 SERIES
Epoch 6-ft | 5-Blades | 230 RPM HVLS Fan
Epoch 1.0 Motor & Controller — 27 Nm / 750 W / 1.0 hp · 4 – 5 m Mounting Height
⚙ Epoch 1.0 – 6 ft (1.8 m) 5-Blade Specifications
Fan Diameter 6 ft (1.8 m)
Number of Blades 5
Blade Profile Aerodynamic Airfoil Design
Blade Material Anodized 6061-T6 Aluminum
Blade Struts Clear Zinc / High Tensile Steel
Blade Width / Thickness 187 mm / 2 mm
Blade End Winglets Reinforced Nylon
Coverage / Radius 4,000 sq.ft. (371 m²) · Radius 28 ft
Space Between Fans / From Wall 56 ft / 12 ft (min)
Air Flow (CFM) 350,000 – 400,000 CFM
Sound Level < 35 dB
Fan Weight 55 kg / 121 lbs
Height From Floor (Recommended) 4 – 5 m
🔌 Motor & Electrical – Epoch 1.0
Motor Platform Epoch 1.0 – Direct Drive PMSM, Gearless
Technology UPF (Unity Power Factor) + PMSM
Max Speed / Power / Torque 230 RPM · 750 W (1.0 hp) · 27 Nm
Input Voltage 200–277V AC, 1 Phase, 50/60 Hz
Power Factor Correction Yes (UPF Integrated)
Operating Unit Options Wireless / Apps · Touch LCD (Modbus) · Analog · Analog + LCD
🛡 Safety & Engineering
Safety System • Safety guy wires for motor + each blade
• Automotive-grade hub & reinforced guy wires
• Designed for UL507 & UL1004 safety standards

📬 For detailed specifications, OEM drawings, bulk pricing, or installation support:
epochfans@falcoemotors.com

You may also like

Everything included in the price

Free ocean freightShipped from our factory at no charge. Typical delivery 45–60 business days.
US duties paid (DDP)We pay import duties and customs fees. No surprise bills at delivery.
ETL ListedCertified by Intertek, Control No. 5014289.
15-year mechanical warrantyPlus 7 years electrical on the direct-drive motor and controller.
Gearless PMSM direct driveNo gearbox, no gear oil, near-silent operation.
Free layout and engineering helpSend your floor plan and we size and place your fans.

How the price compares: a 24 ft Big Ass Fans Powerfoil X4 lists from $9,999 on bigassfans.com. MacroAir and Epic Fans do not publish prices. Source: competitor websites, September 2026.

Will I pay import duties or customs fees?

No. Orders ship Delivered Duty Paid. Epoch pays US import duties and customs fees.

What electrical supply do I need?

Epoch direct-drive fans run on 200–277 V AC single-phase, 50/60 Hz. Check the specifications above for your model.

Can I get drawings or an installation guide?

Yes. Email epochfans@falcoemotors.com or call 877-278-6323 for mounting drawings, spec sheets and installation guidance.
